Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-26
FIP-1.15 Printing error
Procedure Check
Action
YES NO
1
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt, or foreign object?
- Major check parts -
PWBA MCU XFABK(B) (PL9.1.25), AZUSA HVPS
(PL9.1.6), LVPS 230 (PL9.1.5)
Replace and
reattach the parts.
To step 2
2 Is no printing performed? To step 4 To step 3
3
Is the device reset during printing? Go to FIP-2.9,
Noise
To step 4
4
- PWBA MCU XFABK(B) replacement check -
Does this error recur after the defective PWBA MCU
XFABK(B) is replaced with a normal one?
To step 5 Action completed
5
- Interface Cable check -
Does this error recur after the defective Interface Cable
is replace with a normal one?
Host side check Action completed
To Next Page
