Chapter 7 Wiring Data
7.1 Connector [P (plug) / J (jack)]
7-2
7.1 Connector [P (plug) / J (jack)]
7.1.1 List of P/J
P/J Coordiates Remarks
100 H-209 Connection between PWBA MCU and HARNESS ASSY PH
101 G-209 Connection between PWBA MCU and CABLE SENSOR
102 G-210 Connection between PWBA MCU and CABLE HV
103 F-210 Connection between PWBA MCU and FAN ASSY
104 F-210 Connection between PWBA MCU and FAN
105 E-209 Connection between PWBA MCU and ROS ASSY
106 F-209 Connection between PWBA MCU and ROS ASSY
107 F-209 Connection between PWBA MCU and FFC VIDEO
108 G-209 Connection between PWBA MCU and LVPS
109 G-209 Connection between PWBA MCU and HARNESS ASSY MOTOR MAIN
110 H-209 Connection between PWBA MCU and HARNESS ASSY MSI
111 G-209 Connection between PWBA MCU and HARNESS ASSY CRUM
301 J-106 Connection between LVPS and HARNESS ASSY AC IN
302 I-107 Connection between LVPS and HARNESS ASSY FSR
303B D-107
Connection between HARNESS ASSY MANUAL TRAY SNS and SENSOR
500 F-106 Connection between FFC OPP and PWBA LED
1001 C-107 Connection between HARNESS ASSY PH and SENSOR PHOTO
1002 A-107 Connection between HARNESS ASSY PH and SWITCH P/SIZE
1003 B-107 Connection between HARNESS ASSY PH and MOTOR ASSY FEED
1090 B-208
Connection between HARNESS ASSY MOTOR MAIN and MOTOR ASSY MAIN
(The CN101 is printed on the board.)
1101 B-112 Connection between HARNESS ASSY MSI and CLUTCH ROLL FEED (TRAY)
1102 B-113
Connection between HARNESS ASSY MSI and HARNESS ASSY MANUAL
TRAY SNS
1110 C-105 Connection between HARNESS ASSY CRUM and Drum/toner cartridge
3021 C-207 Connection between HARNESS ASSY FSR and FUSER ASSY
CN Coordiates Remarks
1 F-209 Connection between PWBA ESS and FFC OPP (Reference)
4 E-209 Connection between FFC VIDEO and PWBA ESS (Reference)
101 I-209 Connection between CABLE SENSOR and PWBA SENSOR
102 I-209 Connection between PWBA SENSOR and CLUTCH REGI ROLL
103 J-208 Connection between PWBA SENSOR and FUSER ASSY
104 J-209 Connection between PWBA SENSOR and FUSER ASSY
201 G-106 Connection between CABLE HV and HVPS
202 E-106 Connection between HVPS and HARNESS ASSY DB
203 D-106
Connection between HVPS and HARNESS ASSY CR (The “DB” is printed on
the board.)
204 E-105
Connection between HVPS and HARNESS ASSY HV BTR (The “TR” is printed
on the board.)
205 E-105
Connection between HVPS and HARNESS ASSY HV TRANS (The “VG” is
printed on the board.)
206 D-105
Connection between HVPS and HARNESS ASSY HV DT (The “VD” is printed
on the board.)
