Chapter 2 Troubleshooting

2.3 Level 2 FIP

2-29

FIP-2.3 SWITCH P/SIZE error

Procedure Check

Action

YES NO

- Initial check -

Are there errors such as use of parts in different

specifications, attachment error, damage,

transformation, dirt, or foreign object?

- Major check parts -

LVPS 230 (PL9.1.5), HARNESS ASSY PH (PL5.1.30),

SWITCH P/SIZE (PL5.1.29), PWBA MCU XFABK(B)

(PL9.1.25)

Replace and

reattach the parts.

To step 2

- HARNESS ASSY PH check -

Is the J100<=>J1002 connected normally? To step 3

Replace the

HARNESS ASSY

- SWITCH P/SIZE check -

Is the J100<=>SWITCH P/SIZE connected normally?

Replace the

PWBA MCU

XFABK(B)

Replace the

SWITCH P/SIZE
