Fuji Xerox DocuPrint 2050 Service Manual

Chapter 7 Wiring Data
7.3 Wiring Diagram between Parts
7-13
§ 4 PWBA MCU <-> HVPS, Drum/toner cartridge (1/2)
P/J102
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
CN201
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
2
3
1
NC
InterLock5V BEF
InterLock5V AFT
5VDC
EEPROM DataClock
GND
EP ExistCheck (L)
NC
Standard Voltage
T-Roller V-mom
CR_DC On/Off
T- On/Off (L)
T+ On/Off (L)
TR D/A Output
DB_DC D/A Output
DB_AC D/A Output
DB_AC Clock
CR_DC D/A Output
CR_AC On/Off(L)
CR_AC Clock
GND
InterLock24V
2
6
3
5
1
8
4
P/J111
1
2
3
4
5
6
7
CRUM
CN203
KON658CA
EEPROM DataR/W
P/J1110
4
SG
CR
1
2
CN202
DB
DB
: The number is
printed on the board.
**
DRUM/TONER
CARTRIDGE
PL10.1.2
[CABLE HV PL9.1.8]
[HARNESS
ASSY DB
PL9.1.11]
[HARNESS
ASSY CR
PL9.1.10]
[HARNESS ASSY CRUM PL4.1.12]
PWBA MCU
XFABK(B)
PL9.1.25
AZUSA HVPS
PL9.1.6
