Chapter 2 Troubleshooting
2.2 Level 1 FIP
2-6
2.2 Level 1 FIP
2.2.1 Level 1 FIP
The level 1 FIP is the first step for trouble diagnosis. The level 1 FIP isolates the presence of various
troubles including error codes, and the level 2 FIP provides a guide for proceeding of the
troubleshooting.
2.2.2 Flow of Level 1 FIP
Execute the respective
troubleshooting referring
to Chapter 7 Wiring Data.
KON201CA
Ask operator of the failure status.
Does operator operate correctly?
YN
Is a status code indicated?
YN
YN
Explain operator of correct
operation procedures.
Repair referring to status code or
message.
Determine corresponding image
quality failure from contents of
Chapter 3 and execute the procedure
instructed.
Turn power off then on.
Is a status code indicated?
YN
Make a copy in the same mode as the
problem mode. Is a status or message
indicated?
Is it a copy quality failure?
YN
Execute other
corresponding
troubleshooting.
To Next Page
