Page #29 background image
Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-10
2.3.4 Error Code FIP
FIP-1.1 Drum/toner cartridge (No cartridge, Cartridge error)
*: Do not absolutely touch the powered parts, high-voltage output parts, and driving parts for check.
Procedure Check
Action
YES NO
1
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt, or foreign object?
- Major check parts -
PWBA MCU XFABK(B) (PL9.1.25), Drum/toner
cartridge (PL10.1.2), HARNESS ASSY CRUM
(PL4.1.12)
Replace and
reattach the parts.
- There is a tool.
To step 2
- There is no tool.
To step 3
2
- HARNESS ASSY CRUM check -
Does the HARNESS ASSY CRUM function normally?
Select [SENSOR/SWITCH CHECK] on the
DIAGNOSTIC MODE MENU.
Replace the
PWBA MCU
XFABK(B)
Replace the
HARNESS ASSY
CRUM
3
- HARNESS ASSY CRUM check - *
Does the HARNESS ASSY CRUM connect normally?
Replace the
PWBA MCU
XFABK(B)
Replace the
HARNESS ASSY
CRUM
