Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-27
2.3.5 Other FIP
FIP-2.1 LVPS 230 error
*: Do not absolutely touch the powered parts, high-voltage output parts, and driving parts for check.
Procedure Check
Action
YES NO
1
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt, or foreign object?
- Major check parts -
PWBA MCU XFABK(B) (PL9.1.25), LVPS 230 (PL9.1.5)
Replace and
reattach the parts.
To step 2
2
- LVPS 230 check - *
Is 5VDC applied to the J108-4PIN<=>J108-3PIN?
Is 24VDC applied to the J108-6PIN<=>J108-5PIN?
To step 3
Replace the LVPS
230
3
- DC Cable check -
Is the LVPS 230<=>P108 connect normally?
Replace the
PWBA MCU
XFABK(B)
Replace the LVPS
230
