Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-7
2.3 Level 2 FIP
2.3.1 Level 2 FIP
The Level 2 FIP is the trouble diagnostic procedure to sort various troubles in addition to the error
codes. In the troubleshooting, executing the steps given in the FIP or checking procedure allows you
to find out a cause of trouble in a short time.
2.3.2 Error / Status Code List
Error
Printer LED
(BLK=Blink)
Simple Monitor Message
FIP
Green Red Printing Status Window
Status
Window
001-358
FAN Alarm
OFF BLK
An error occurred on the
printer (001-358)
Attention
required
FIP-1.12
003-350
Communication Error
OFF BLK
An error occurred on the
printer (003-350)
Attention
required
FIP-1.14
006-370
ROS Alarm
OFF BLK
An error occurred on the
printer (006-370)
Attention
required
FIP-1.11
006-370
Scanner Motor Alarm
OFF BLK
An error occurred on the
printer (006-370)
Attention
required
FIP-1.11
006-371
BD Alarm
OFF BLK
An error occurred on the
printer (006-371)
Attention
required
FIP-1.14
006-372
LASER Alarm
OFF BLK
An error occurred on the
printer (006-372)
Attention
required
FIP-2.2
007-340
Main Motor Alarm
OFF BLK
An error occurred on the
printer (007-340)
Attention
required
FIP-1.13
009-361
Drum/toner cartridge
(Drum/toner cartridge)
Error
OFF BLK
An error occurred on the
printer (009-361)
Attention
required
FIP-1.1
010-397
Fuser Alarm
OFF BLK
An error occurred on the
printer (010-397)
Attention
required
FIP-1.10
No Cartridge
OFF ON
Drum/Toner cartridge is not
set up
Consumables
not loaded
FIP-1.1
Cartridge Type Error
OFF ON
Wrong drum/toner cartridge is
installed
Unsupported
consumables
FIP-1.1
Paper Size Error
BLK ON
Paper size different from the
specified size for Bypass Tray
is loaded
Paper size different from the
specified size for Tray1 is
loaded
No Message
FIP-1.2
Paper Empty OFF ON No Message No Paper FIP-1.3
Paper Jam
OFF ON
Paper jammed at the main
assembly
Paper jammed at the paper-
feeding
Paper Jam
FIP-
1.1.4/1.5/
1.6/1.7
To Next Page
