Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-13
FIP-1.4 MIS FEED JAM (Jam or pick error)
<To be continued to the next page>
Procedure Check
Action
YES NO
1
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt, or foreign object?
- Major check parts -
PLATE ASSY GEAR (PL5.1.26/PL7.1.3), ROLL ASSY
FEED REAR (PL5.1.36), ROLL FEED FRONT D
(PL5.1.35), ROLL FEED REAR 2 (PL5.1.38), ROLL
FEED ASSY TRAY (PL3.1.21), FEED MOTOR ASSY
(PL5.1.28), PWBA SENSOR (PL4.1.17), REGI
SENSOR (mounted on the PWBA SENSOR),
ACTUATOR ASSY REGI (PL4.1.19), Paper Cassette,
PLATE ASSY BOTTOM 250 (PL2.1.3), PWBA MCU
XFABK(B) (PL9.1.25)
Replace and
reattach the parts.
To step 2
2
Is curled paper used? Use uncurled
paper.
To step 3
3
- Paper size check -
Is the paper size based on the specifications? To step 4
Use the paper
based on the
specifications.
4
- Paper position check -
Does paper pass through the ACTUATOR ASSY REGI
at occurrence of the error?
To step 9
- There is a tool.
To step 5
- There is no tool.
To step 6
5
- FEED MOTOR ASSY check -
Does the FEED MOTOR ASSY rotate normally?
Select the [MP PICK TEST][1ST PICK TEST] on the
DIAGNOSTIC MODE MENU.
To step 6
Replace the
FEED MOTOR
ASSY
6
- PLATE ASSY GEAR check -
Does each gear in the PLATE ASSY GEAR rotate
normally?
Remove the FRAME ASSY MAIN, rotate the gear on
the top by hands, then visually check that the gear
rotates normally
To step 7
Replace the faulty
part.
7
- ROLL FEED FRONT D/ROLL FEED REAR 2/ROLL
FEED ASSY check -
Is paper fed normally during printing?
(Do the ROLL FEED FRONT D and paper slip?)
To step 9 To step 8
8
- Paper Cassette check -
Does the PLATE BOTTOM 250 lift normally at removal
of the Paper Cassette?
To step 9
Replace the faulty
part.
To Next Page
