Fuji Xerox DocuPrint 2050 Service Manual

Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-14
<Continued from the preceding page>
Procedure Check
Action
YES NO
9
- ACTUATOR ASSY REGI check -
Does the ACTUATOR ASSY REGI run smoothly?
- There is a tool.
To step 10
- There is no tool.
Go to FIP-2.4,
PWBA SENSOR
error
Replace the
ACTUATOR
ASSY REGI
10
- REGI. SENSOR check -
Does the REGI. SENSOR function normally?
Select [SENSOR/SWITCH CHECK] on the
DIAGNOSTIC MODE MENU.
Replace the
PWBA MCU
XFABK(B)
Go to FIP-2.4,
PWBA SENSOR
error
