Fuji Xerox DocuPrint 2050 Service Manual

Chapter 7 Wiring Data
7.3 Wiring Diagram between Parts
7-17
§ 6 PWBA MCU <-> PWBA ESS <-> PWBA LED (2/2)
Signal line name Reference
CPRDY (L) Controller ready signal
PRINT (L) Print control signal
CBSY (L) Controller busy signal
CMD (L) Command control signal
CCLK Controller Clock signal
VDO (L) Video signal
BD (L) Beam Detection sense signal
STS (L) Status signal
SBSY (L) Status busy signal
VSREQ (L) Vertical synchronization signal request
RDY (L) Ready signal
PPRDY (L) Print Power Ready signal
