Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-11
FIP-1.2 Paper size unmatching (Paper size error)
Procedure Check
Action
YES NO
1
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt, or foreign object?
- Major check parts -
PWBA SENSOR (PL4.1.17), SWITCH P/SIZE
(PL5.1.29), REGI SENSOR (mounted on the PWBA
SENSOR), ACTUATOR ASSY REGI (PL4.1.19),
WHEEL SIZE Paper Cassette, PWBA MCU XFABK(B)
(PL9.1.25)
Replace and
reattach the parts.
To step 2
2
- Paper size check -
Is the paper size based on the specifications? To step 3
Use the paper
based on the
specifications.
3
- Paper size sense mechanism check -
Does the paper size set to the Paper Cassette match
the ON/OFF combination of SWITCH P/SIZE?
Go to FIP-2.3,
SWITCH P/SIZE
error
Replace the faulty
part.
4
- ACTUATOR ASSY REGI check -
Does the ACTUATOR ASSY REGI run smoothly?
- There is a tool.
To step 5
- There is no tool.
Go to FIP-2.4,
PWBA SENSOR
error
Replace the
ACTUATOR
ASSY REGI
5
- REGI. SENSOR check -
Does the REGI. SENSOR run smoothly?
Select [SENSOR/SWITCH CHECK] on the
DIAGNOSTIC MODE MENU.
Replace the
PWBA MCU
XFABK(B)
Go to FIP-2.4,
PWBA SENSOR
error
