Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-24
FIP-1.13 MOTOR ASSY MAIN alarm
Procedure Check
Action
YES NO
1
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt, or foreign object?
- Major check parts -
GEAR ASSY (PL7.1.1), MOTOR ASSY MAIN (PL7.1.2),
FUSER ASSY CL CH (PL7.1.15), REGISTRATION
ASSY (PL4.1.30), ROLL ASSY REGI (PL4.1.35), ROLL
ASSY PRESS (PL4.1.36), Drum/toner cartridge
(PL10.1.2)
Replace and
reattach the parts.
- There is a tool.
To step 2
- There is no tool.
To step 3
2
- MOTOR ASSY MAIN operation check -
Does the MOTOR ASSY MAIN run normally?
Select [MOTOR ASSY MAIN TEST] on the
DIAGNOSTIC MODE MENU.
Go to FIP-2.7,
GEAR ASSY
error
To step 3
3
- GEAR ASSY check -
Does each gear in the GEAR ASSY rotate smoothly?
Remove the FUSER ASSY CL CH and the Drum/toner
cartridge, rotate the gears by hands, and visually check
that the gears function normally.
To step 4
Replace the
GEAR ASSY
4
- FUSER ASSY CL CH check -
Does each gear or roll of the FUSER ASSY CL CH
rotate smoothly?
Remove the FUSER ASSY CL CH, rotate the gears by
hand, and visually check that the gears function
normally.
To step 5
Replace the
FUSER ASSY CL
CH
5
- REGISTRATION ASSY check -
Does the ROLL ASSY REGI and ROLL ASSY PRESS
rotate smoothly?
Rotate the ROLL ASSY PRESS by hands for check.
To step 6
Replace the
REGISTRATION
ASSY
6
- Drum/toner cartridge check -
Does the drum of the Drum/toner cartridge rotate
smoothly?
Rotate the gear attached to the drum by hands for
check.
Go to FIP-2.7,
GEAR ASSY
error
Replace the
Drum/toner
cartridge
To Next Page
