Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-18
FIP-1.7 Exit jam (Jam or pick error)
*: Do not absolutely touch the powered parts, high-voltage output parts, and driving parts for check.
Procedure Check
Action
YES NO
1
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt, or foreign object?
- Major check parts -
SENSOR ACTUATOR (mounted on the FUSER ASSY
CL CH), ROLL ASSY EXIT (mounted on the FUSER
ASSY CL CH), FUSER ASSY CL CH (PL7.1.15),
SENSOR EXIT (mounted on the FUSER ASSY CL CH),
PWBA MCU XFABK(B) (PL9.1.25)
Replace and
reattach the parts.
To step 2
2
Does paper remain in the SENSOR ACTUATOR? Remove the
paper.
To step 3
3
- Check of paper entry to the ROLL ASSY EXIT -
Does paper normally enter between the ROLL ASSY
EXIT of the FUSER ASSY CL CH and the pinch roll?
Execute the test printing for visual check.
To step 4
Replace the
FUSER ASSY CL
CH
4
- SENSOR ACTUATOR check -
Does the SENSOR ACTUATOR run smoothly?
- There is a tool.
To step 5
- There is no tool.
Go to FIP-2.5,
Sensor Exit error
Replace the
FUSER ASSY CL
CH
5
- Sensor Exit check - *
Does the Sensor Exit function normally?
Select [SENSOR/SWITCH CHECK] on the
DIAGNOSTIC MODE MENU.
Replace the
PWBA MCU
XFABK(B)
Go to FIP-2.5,
Sensor Exit error
To Next Page
