Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-17
<Continued from the preceding page>
*: Do not absolutely touch the powered parts, high-voltage output parts, and driving parts for check.
Procedure Check
Action
YES NO
9
- PLATE DT SAW check -
Is the PLATE DT SAW dirty, dusty, or transformed?
Replace/Clean
the PLATE DT
SAW
To step 10
10
- HEAT ROLL/PRESSURE ROLL rotation check -
Does the HEAT ROLL or PRESSURE ROLL of the
FUSER ASSY CL CH rotate normally?
To step 11
Replace the
FUSER ASSY CL
CH
11
- Check of paper entry to ROLL ASSY EXIT -
Does paper normally enter between the ROLL ASSY
EXIT of the FUSER ASSY CL CH and the pinch roll?
Execute the test printing for visual check.
To step 12
Replace the
FUSER ASSY CL
CH
12
- SENSOR ACTUATOR check -
Does the SENSOR ACTUATOR run smoothly?
- There is a tool.
To step 13- There
is no tool. Go to
FIP-2.5, Sensor
Exit error
Replace the
FUSER ASSY CL
CH
13
- Sensor Exit check - *
Does the Sensor Exit function normally?
Select [SENSOR/SWITCH CHECK] on the
DIAGNOSTIC MODE MENU.
Replace the
PWBA MCU
XFABK(B)
Go to FIP-2.5,
Sensor Exit error
To Next Page
