Chapter 3 Image Quality Troubleshooting
3.5 Image Quality FIP
3-28
FIP-P15 "Unfused toner"
P15
Phenomenon/Initial check Print sample
Paper is waved and wrinkled.
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt or foreign object?
- Major check parts -
CASSETTE ASSY 250 CL (PL2.1.1)
Item Check
Action
(at occurrence of error)
1 Is the ream of papers in the specified range? Set papers in the specified range.
2
Is the heater of the FUSER ASSY CL CH turned on? When the heater is turned on,
replace the FUSER ASSY CL
CH; otherwise, check whether the
heater of the FUSER ASSY CL
CH is conductive.If it is
conductive, replace the AZUSA
HVPS. If it is not conductive,
replace the FUSER ASSY CL
CH.
3
Does this error occur after the AZUSA HVPS is
replaced?
Replace the FUSER ASSY CL
CH.
4
Does this error occur after the FUSER ASSY CL CH is
replaced?
Replace the PWBA MCU.
To Next Page
