Chapter 4 Disassembly/Assembly and Adjustment
4.2 Disassembly/Assembly
4-29
REP4.2 REGISTRATION ASSY (PL4.1.30)
<Removal>
1) Separate the CASSETTE ASSY 250 CL (PL2.1.1) from the printer by 15cm.
2) Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT.
3) Remove the COVER ASSY STACK CL. (REP1.7)
4) Remove the COVER ASSY PWB. (REP9.5)
5) Remove the COVER ASSY TOP CL. (REP1.4)
6) Remove the COVER SIDE LEFT CL. (REP1.1)
7) Remove the PWBA SENSOR. (REP4.7)
8) Remove a screw (gold, with flange, 8mm) securing the STOPPER CVR F L (PL4.14), pull out the
STOPPER CVR F L from the shaft of the printer frame and release.
9) Remove the COVER ASSY RIGHT CL. (REP1.2)
10) Remove the COVER MIDDLE CL. (REP1.3)
11) Remove the FRAME BASE RTD TRAY HN. (Refer to REP 3.5)
12) Remove the FUSER ASSY CL CH. (REP7.3)
13) Remove the GEAR ASSY. (REP7.1)
14) Remove a screw (gold, with flange, 8mm), move the DUCT ASSY AIR (PL4.1.21) while avoiding
the CHASSIS CONTROLLER (PL9.1.27).
15) Remove the four screws (gold, tapping, 8mm) securing the REGISTRATION ASSY and lift the left
side of the assembly to remove the assembly to the upper left.
NOTE
The work is good when removing the COVER FRONT RIGHT (PL3.1.30).
(Refer to REP 3.6)
To Next Page
