Chapter 2 Troubleshooting
2.3 Level 2 FIP
2-16
FIP-1.6 REGI. JAM (Jam or pick error)
*: Do not absolutely touch the powered parts, high-voltage output parts, and driving parts for check.
<To be continued to the next page>
Procedure Check
Action
YES NO
1
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt, or foreign object?
- Major check parts -
FUSER ASSY CL CH (PL7.1.15), SENSOR EXIT
(mounted on the FUSER ASSY CL CH), SENSOR
ACTUATOR (mounted on the FUSER ASSY CL CH),
PWBA MCU XFABK(B) (PL9.1.25), GEAR ASSY
(PL7.1.1), ROLL ASSY REGI (PL4.1.35), ROLL ASSY
BTR (PL8.1.13), PLATE DT SAW (PL8.1.4), Drum/toner
cartridge (PL10.1.2), ROLL ASSY EXIT (mounted on
the FUSER ASSY CL CH)
Replace and
reattach the parts.
To step 2
2
Is curled paper used? Use uncurled
paper.
To step 3
3
- Paper size check -
Is the paper size based on the specifications? To step 4
Use the paper
based on the
specifications.
4
- GEAR ASSY check -
Does the CLUTCH REGI ROLL A gear, Drum/toner
cartridge gear, gear in the GEAR ASSY for the FUSER
ASSY CL CH of H/R GEAR rotate normally?
To step 5
Replace the
GEAR ASSY
5
- ROLL ASSY REGI check -
Does the ROLL ASSY REGI and ROLL ASSY PRESS
rotate normally?
- There is a tool.
To step 6
- There is no tool.
To step 7
Replace the
REGISTRATION
ASSY
6
- CLUTCH REGI ROLL A check -
Does the CLUTCH REGI ROLL A function normally?
Select [REGI. ROLL CLUTCH TEST] on the
DIAGNOSTIC MODE MENU.
To step 7
Go to FIP-2.6,
CLUTCH REGI
ROLL A error
7
- CLUTCH REGI ROLL A check - *
Does the lead edge of paper pass through the ROLL
ASSY REGI unit at occurrence of this error?
Check the paper stop position and confirm that the
CLUTCH REGI ROLL A functions normally.
To step 8
Go to FIP-2.6,
CLUTCH REGI
ROLL A error
8
- ROLL BTR or Drum rotation check -
Does the lead edge of paper pass through the contact
between the ROLL BTR and Drum at occurrence of this
error?
Check the paper stop position and confirm that the
ROLL BTR and Drum function normally.
To step 9
Replace the
ROLL ASSY BTR
or the Drum/toner
cartridge
To Next Page
