Chapter 3 Image Quality Troubleshooting
3.5 Image Quality FIP
3-23
FIP-P10 "Toner at random positions"
P10
Phenomenon/Initial check Print sample
Toner on some non-print parts
(toner at random)
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt or foreign object?
- Major check parts -
FUSER ASSY CL CH (PL7.1.15)
Item Check
Action
(at occurrence of error)
1
- FUSER ASSY CL CH error -
Is toner detected before the FUSER ASSY CL CH?
Replace the FUSER ASSY CL
CH.
Clean the inside of the device.
