Chapter 3 Image Quality Troubleshooting
3.5 Image Quality FIP
3-24
FIP-P11 "Blotted print-out"
P11
Phenomenon/Initial check Print sample
Print-out is blotted.
- Initial check -
Are there errors such as use of parts in different
specifications, attachment error, damage,
transformation, dirt or foreign object?
- Major check parts -
FUSER ASSY CL CH (PL7.1.15)
Item Check
Action
(at occurrence of error)
1 Is paper set correctly? Set paper correctly.
2 Is the specified paper used? Use the specified paper.
3
- FUSER ASSY CL CH attachment error -
Is the FUSER ASSY CL CH attached securely?
Reattach the FUSER ASSY CL
CH.
To Next Page
