Fuji Xerox DocuPrint 2050 Service Manual

Chapter 4 Disassembly/Assembly and Adjustment
4.2 Disassembly/Assembly
4-54
<Replacement>
Perform the removal procedures in the reverse order.
NOTE
The left side screw securing the FUSER ASSY CL CH shall be of the stud type.
NOTE
Lay the harness of HARNESS ASSY FUSER (PL9.1.7) as shown in figure.
