Fuji Xerox DocuPrint 2050

Chapter 4 Disassembly/Assembly and Adjustment
4.2 Disassembly/Assembly
4-65
<Replacement>
Perform the removal procedures in the reverse order.
NOTE
Lay the harnesses as shown in figure.
HARNESS ASSY HV BTR
HARNESS ASSY HV DT
HARNESS ASSY HV TRANS
Hook
AZS424CA
14)
15)
16)
13)
17)
Hook
