5.3.12. Clock configuration register 1 (RCU_CFG1)
Address offset: 0x2C
Reset value: 0x0000 0000
This register can be accessed by byte(8-bit), half-word(16-bit) and word(32-bit)
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
Reserved
I2S2SEL
I2S1SEL
PREDV0
SEL
rw
rw
rw
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
PLL2MF[3:0]
PLL1MF[3:0]
PREDV1[3:0]
PREDV0[3:0]
rw
rw
rw
rw
Bits
Fields
Descriptions
31:19
Reserved
Must be kept at reset value
18
I2S2SEL
I2S2 Clock Source Selection
Set and reset by software to control the I2S2 clock source.
0: System clock selected as I2S2 source clock
1: (CK_PLL2 x 2) selected as I2S2 source clock
17
I2S1SEL
I2S1 Clock Source Selection
Set and reset by software to control the I2S1 clock source.
0: System clock selected as I2S1 source clock
1: (CK_PLL2 x 2) selected as I2S1 source clock
16
PREDV0SEL
PREDV0 input Clock Source Selection
Set and reset by software.
0: HXTAL selected as PREDV0 input source clock
1: CK_PLL1 selected as PREDV0 input source clock
15:12
PLL2MF[3:0]
The PLL2 clock multiplication factor
Set and reset by software.
00xx: reserve
010x: reserve
0110: (PLL2 source clock x 8)
0111: (PLL2 source clock x 9)
1000 :(PLL2 source clock x 10)
1001: (PLL2 source clock x 11)
1010: (PLL2 source clock x 12)
1011: (PLL2 source clock x 13)
1100: (PLL2 source clock x 14)
1101: (PLL2 source clock x 15)
1110: (PLL2 source clock x 16)
