IRC8MSTB
IRC8M Internal 8MHz RC Oscillator stabilization Flag
Set by hardware to indicate if the IRC8M oscillator is stable and ready for use.
0: IRC8M oscillator is not stable
1: IRC8M oscillator is stable
0
IRC8MEN
Internal 8MHz RC oscillator Enable
Set and reset by software. This bit cannot be reset if the IRC8M clock is used as the
system clock. Set by hardware when leaving Deep-sleep or Standby mode or the
HXTAL clock is stuck at a low or high state when CKMEN is set.
0: Internal 8 MHz RC oscillator disabled
1: Internal 8 MHz RC oscillator enabled
5.3.2. Clock configuration register 0 (RCU_CFG0)
Address offset: 0x04
Reset value: 0x0000 0000
This register can be accessed by byte(8-bit), half-word(16-bit) and word(32-bit)
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
Reserved
PLLMF[4]
ADCPSC[
2]
CKOUT0SEL[3:0]
USBFSPSC[1:0]
PLLMF[3:0]
PREDV0
_LSB
PLLSEL
rw
rw
rw
rw
rw
rw
rw
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
ADCPSC[1:0]
APB2PSC[2:0]
APB1PSC[2:0]
AHBPSC[3:0]
SCSS[1:0]
SCS[1:0]
rw
rw
rw
rw
r
rw
Bits
Fields
Descriptions
31:30
Reserved
Must be kept at reset value.
29
PLLMF[4]
Bit 4 of PLLMF
see bits 21:18 of RCU_CFG0
28
ADCPSC[2]
Bit 2 of ADCPSC
see bits 15:14 of RCU_CFG0
27:24
CKOUT0SEL[3:0]
CKOUT0 Clock Source Selection
Set and reset by software.
00xx: No clock selected
0100: System clock selected
0101: High Speed 8M Internal Oscillator clock selected
0110: External High Speed oscillator clock selected
0111: (CK_PLL / 2) clock selected
