GD32VF103 User Manual

405

Table 18-7. I2S interrupt

Interrupt flag

Description

Clear method

Interrupt

enable bit

TBE

Transmit buffer empty

Write SPI_DATA register

TBEIE

RBNE

Receive buffer not empty

Read SPI_DATA register

RBNEIE

TXURERR

Transmission underrun error

Read SPI_STAT register

ERRIE

RXORERR

Reception overrun error

Read SPI_DATA register and

then read SPI_STAT register.

FERR

I2S format error

Read SPI_STAT register
