GD32VF103 User Manual
367
Figure 17-13. Programming model for master receiving using solution B(10-bit address
mode)
IDLE
Master generates START
condition
Master sends Address
Slave sends Acknowledge
Master sends Header
Slave sends Acknowledge
SCL stretched by master
Slave sends DATA(1)
Master sends Acknowledge
……（Data transmission）
Slave sends DATA(N)
Master DON'T send Ack
Master generates STOP
condition
1) Software initialization
Set ADD10SEND
4) Clear ADD10SEND
Set ADDSEND
4) Clear ADDSEND
Set RBNE
Set RBNE and BTC
6) Read DATA(N-3)
Set RBNE
5) Read DATA(1)
Slave sends DATA(N-1)
Master sends Acknowledge
Set RBNE
8) Read DATA(N-2)
I2C Line State Hardware Action
Software Flow
2) Set START
Set SBSEND
SCL stretched by master
3) Clear SBSEND
SCL stretched by master
4) Set START
Master generates repeated
START condition
Set SBSEND
4) Clear SBSEND
SCL stretched by master
Master sends Header
Slave sends Acknowledge
Set ADDSEND
4) Clear ADDSEND
SCL stretched by master
7) Clear ACKEN
Slave sends DATA(N-2)
Master sends Acknowledge
SCL stretched by master
Set RBNE and BTC
8) Read DATA(N-1)
7) Set STOP
SCL stretched by master
9) Read DATA(N)
17.3.8. SCL line stretching
The SCL line stretching function is designed to avoid overflow error in reception and underflow
error in transmission. As is shown in Programming Model, when the TBE and BTC bit of a
transmitter is set, the transmitter stretches the SCL line low until the transfer buffer register is
