Hioki 8835-01 - System Screen Settings; Chapter 9 SYSTEM Screen Settings

179
────────────────────────────────────────────────────
8.6 Using the Analog Trigger Function
────────────────────────────────────────────────────
T
rigger leve
l
F
ilter widt
h
T
riggering occurs
T
riggering does not occur here
R
ising trigger slope :
Trigger filter
・Triggering occurs when the trigger conditions are met within the filter width.
・This is useful to prevent spurious triggering by noise.
・The filter width is specified by the number of divisions of the memory recorder
function, while it is fixed to 10 ms, which is enabled and disabled using the
ON/OFF keys, for the recorder function.
Method Screen: STATUS 2, DISPLAY
1. Select the level trigger.
(1) Call up the STATUS 2 or DISPLAY screen.
(2) Move the flashing cursor to the position
shown in the figure on the left.
(3) Use the function keys to select level trigger.
