1.3 Identification of Controls and Indicators
────────────────────────────────────────────────────
2
3
1
Top view
4
5
Bottom view
1
2
3
4
5
Ventilation slots
Handle Serves for transporting the 8835-01.
Logic probe connectors Input connector for the logic input section, designed for
the dedicate logic probes (CH A, CH B, CH C, CH D).
Ventilation slots
Tilt support
