7.7.3 Setting Integral Measurement 146
7.7.4 Setting for Measuring Pulse Duty Ratio
148
7.7.5 Setting for Measuring Voltage
149
7.7.6 Setting for Measuring Current
150
7.8 Making the Settings of the 8946 4 ch ANALOG UNIT 152
7.8.1 Settings 152
7.8.2 Setting the Input Coupling
153
7.9 Making the Settings of the 8947 CHARGE UNIT 154
7.9.1 Settings 154
7.9.2 Setting for Measuring Acceleration
155
7.9.3 Setting for Measuring Voltage
159
7.10 Making Logic Input Settings 160
7.11 Copying Channels
162
7.12 Arbitrary Setting of Voltage Axis Magnification/
Compression and Display Range
163
7.13 Input Level Monitor Function
166
7.14 Channel Guide
168
Chapter 8 Trigger Functions 169
8.1 Overview 169
8.2 Setting the Trigger Mode 171
8.3 Setting the Pre-trigger
(Memory Recorder and RMS Recorder Functions)
172
8.4 Trigger Timing (Recorder Function)
175
8.5 Setting Trigger Source AND/OR Linking
176
8.6 Using the Analog Trigger Function
177
8.6.1 Level Trigger (RMS Recorder Function Excluded) 178
8.6.2 Window-In, Window-Out Trigger
(RMS Recorder Function Excluded)
182
8.6.3 Voltage Drop Trigger (Memory Recorder Function Only)
185
8.6.4 Period Trigger (RMS Recorder Function Excluded)
187
8.6.5 RMS Level Trigger (RMS Recorder Function Only)
191
8.7 Using the Logic Trigger Function 194
8.8 Using the Timer Trigger Function
196
8.9 Using the External Trigger Function
199
8.10 Manual Trigger 200
8.11 Trigger Output Connector
200
