HP MSM7XX User Manual

Controller teaming
Mobility support
8-28
Single controller team operating with non-teamed
controllers
In this type of setup, the team is configured as the primary mobility controller and the non-
teamed controllers set the IP address of primary controller parameter to the team IP
address. (In this scenario, the team IP address is defined on the LAN port of the team
manager.)
Configure the team
1. Start the management tool on the team manager by pointing your browser to the team IP
address.
2. Select Team: [name] >> Management > Device discovery.
3. Select Mobility controller discovery.
4. Select This is the primary mobility controller.
1
Primary mobility
controller
L3 switch
2
Controller team Independent controllers
3
4
Controlled APs
1.1
Team IP =
192.168.1.99
1.2 3.1 4.1
