HP MSM7XX User Manual

Mobility traffic manager
Scenario 4: Assigning home networks on a per-user basis
9-38
Scenario 4: Assigning home networks on a
per-user basis
This scenario illustrates how to assign home networks on a per-user basis using RADIUS
attributes.
How it works
In this scenario, wireless services have been added to two wired networks. A single
controller and multiple APs are installed on each network. The two networks are connected
with an L3 switch. The following diagram provides an overview of the setup. (A single AP is
shown on each network for clarity).
Wireless clients receive their DHCP address from the controller on their network, or use a
static IP addressing scheme.
User A roams from AP 1 to AP 2
W
L
A
N
10.2
1
User A
W
L
A
N
User A
1
LAN port
192.168.10.1/24
Primary
mobility
controller
2
LAN port
192.168.20.1/24
Network 1
192.168.10.0
20.2
2
Network 2
192.168.20.0
RADIUS
server
Home network via
RADIUS = Net1
L3 switch
