HP MSM7XX

Network configuration
IP QoS
3-35
Settings
 Profile name: Specify a unique name to identify the profile.
 Protocol: Specify an IP protocol to use to classify traffic by specifying its Internet
Assigned Numbers Authority (IANA) protocol number. Protocol numbers are pre-defined
for a number of common protocols. If the protocol you require does not appear in the list,
select Other and specify the appropriate number manually. You can find IANA-assigned
protocol numbers on the Internet.
 Start port/ End port: Optionally specify the first and last port numbers in the range of
ports to which this IP QoS profile applies. To specify a single port, specify the same port
number for both Start port and End port. Port numbers are pre-defined for a number of
common protocols. If the protocol you require does not appear in the list, select Other
and specify the appropriate number manually.
Note To accept traffic on all ports for a specified protocol, set Start port to Other and 0. Also
set End port to 65535.
 Priority: Select the priority level that will be assigned to traffic that meets the criteria
specified in this IP QoS profile.
Note It is strongly recommended that you reserve Very high priority for voice applications.
Example
This example shows how to create two IP QoS profiles and associated them with a VSC. The
two profiles are:
 Voice: Provides voice traffic with high priority.
 Web: Provides HTTP traffic with low priority.
Create the profiles
1. Select Network > IP QoS, and then Add New Profile. The IP QoS Profile page opens.
2. Under Profile name, specify Voice.
3. Under Protocol, from the drop-down list select TCP.
4. Under Start port, from the drop-down list select SIP. Start port and End port are
automatically populated with the correct value: 5060.
