Mobility traffic manager
Scenario 3: Centralized traf
fic on a c
ontroller with per-user traffic routing
9-34
8.
Select
Egress interface
, and under it select
Egress VLAN ID
an
d set it to
40
.
9.
Select
Save
. The profiles list should now look like this:
10.
Select
Controller >> Users > User accounts
. Init
ially
, no ac
counts are defined.
