LLDP
Configuring LLDP on an AP
17-12
L2 priority
Select the layer 2 priority setting. This setting is used instead of the Default traffic priority
set for the switch port. Supported settings are:
DiffServ
This value only applies if VLAN tagging is set to Tagged.
Specify a value for the Differentiated Services codepoint (DSCP) field in IPv4 and IPv6
packet headers (as defined in RFC2474). The codepoint is composed of the six most
significant bits of the DS field.
L2 priority QoS queue
Low - 1
Low - 2
4
Normal - 0
Normal - 3
3
High - 4
High - 5
2
Very high - 7
Very high - 7
1
DiffServ codepoint (DSCP) value QoS queue
> 33 1
26 - 33 2
18 - 25 3
1 - 17 4
0 Disabled
