It is not mandatory to set Filters. When the Filter Settings field is left blank, the system will capture all
packets.
• Enable Promiscuous Mode: Select the Enable Promiscuous Mode check box, if required.
When you enable Promiscuous mode, SARVAM UCS will capture all network traffic. However, this will
work only in a non-switched environment.
When Promiscuous Mode check box is disabled, the system will capture only traffic that is directly related
to it. Only traffic to, from or routed through SARVAM will be picked up by the PCAP Trace.
• Click Submit.
'Filter Setting' and 'Promiscuous Mode' (enabled) will not be cleared during power down.
• Click the Start button to begin the capturing of the packets.
• Click the Stop button to stop packet capture.
OR
• Wait for the system to stop packet capturing. The system stops packet capturing once the maximum
allotted memory of 10 MB (RAM) is utilized.
• Total Bytes: Bytes captured as per the filter setting will be displayed as Total Bytes.
• Status: It displays the Number of Packets and bytes captured as per the filter setting.
Capturing of packets will not stop if you open any other page of Jeeves. So, you may continue using
Jeeves for any other purpose while PCAP Trace is being used.
• When the packet capturing is stopped (by you or the system), click Save Trace File button to save the files
on the PC.
The current packets captured will not be deleted after you have saved the trace file. The current packets
will be deleted when you start the PCAP capture again.
• Now, you can open the trace files using Wireshark or Ethereal or any other similar software which
supports opening of trace files.
If you select Remote as the Location:
Configure the following:
• Listening Interface: By default, WAN is selected.
dst host ip address dst host 192.168.1.176
Capture packets if the destination IP address
is 192.168.1.176.
host ip address host 192.168.1.176
Capture packets if either source or destination IP address
is 192.168.1.176
Filter Type Filter Setting Logic
