Matrix ETERNITY NE System Manual 257
• Click Location 1 and configure the following parameters.
Parameter Description/Action to be Taken
Applicable Open SIP Phone
Variant
Enable Device
Select the Enable Device check box. Default:
Disabled.
Matrix SPARSH VP710
Location
Name
Configure the Location Name to identify the
Open SIP Phone. The Location Name can be a
maximum of 18 characters. Default: Blank.
Matrix SPARSH VP710
Device Type
Select Device Type as MATRIX SPARSH
VP710 - Standard SIP.
Matrix SPARSH VP710
MAC Address
Enter the MAC Address of the SPARSH VP710
phone to be connected at this location. Default:
Blank.
SARVAM UCS validates the phone on the
basis of the MAC Address, and provides
configuration on validation.
Matrix SPARSH VP710
Authenticate
HTTP
Provisioning
request
Select the Authenticate HTTP Provisioning
request check box to authenticate HTTP
request for security reason. Default: Disabled.
If you are using the Open SIP Phone from the
Public IP Address, we recommend you to
enable this option.
SARVAM UCS validates the Open SIP Phone
on the basis of the SIP ID and HTTP
Authentication Password and provides
configuration on validation.
Make sure, you have configured SIP ID as
HTTP User Name and HTTP Authentication
Password as HTTP Password in the Open SIP
Phone.
Matrix SPARSH VP710
Registrar
Server
Address
Select the appropriate Registrar Server
Address according to your installation
scenario
a
to register the Open SIP Phone with
the SIP Registrar of SARVAM UCS. Default:
Use Ethernet IP Address.
Matrix SPARSH VP710
Dial Plan
b
Select the desired Dial Plan. Default: 1
The Phone will detect end of dialing as per the
rules configured in the Dial Plan selected here.
For instructions, see “Dial Plan for SIP
Extension”.
Matrix SPARSH VP710
Transport
Mode
Select the protocol to be used to transport the
SIP messages. Default: TCP
Matrix SPARSH VP710
