You may also plug in a headset with an RJ9 connector into the headset port at the bottom of the phone,
marked with the symbol .
• Connect to the IP Network.
• Plug one end of the Ethernet Cable into the LAN Port at the bottom of the phone, marked with the
symbol and the other end to the IP Network — A Router or LAN Switch.
• Connect a PC to the Phone.
• Plug one end of the Ethernet Cable into the PC Port at the bottom of the phone, marked with the
symbol and the other end into the LAN Port of your PC/LAN Switch.
• Connect DSS532 with the Phone.
• To connect DSS532 with the phone, plug one end of the RJ11 cable into the AUX Port of the phone and
the other end into the IN Port of the DSS532. For installation, see “Installing DSS532 with SPARSH
VP510”.
• Connect the Power Supply.
• It is a PoE enabled phone and can be powered over Ethernet by connecting it to a PoE enabled LAN
Switch (IEEE 802.3af Compliant).
If you do not want to use PoE, plug in the connector of the Adapter into the power jack (DC Jack) at the
bottom of the phone, marked with the symbol . Plug in the Power Adapter into a power
outlet.
• If both the power options, that is, PoE as well as Power Adapter are available to the phone, then the
phone will derive power from the PoE enabled LAN Switch.
• The IP phone should be used with Matrix original power adapter (5V/2A) only. The use of any third-
party power adapter may cause damage to the phone.
• Switch ON power supply.
When you power the phone, the boot process will be initiated in the following sequence.
• All keys with LED, including the Speaker key, and the Ringer LED, will glow.
• The LCD display will light up and the booting message appears.
• Then the ‘Loading...’ message appears on the phone display.
• The phone will start loading the Extended IP Phone Firmware.
It will display current firmware being loaded.
• After loading the firmware, the phone will prompt you to change Network settings.
• Wait for a few seconds.
