DMTA-10045-01EN, Rev. E, August 2016
Specifications
217
A.6 Alarms, Connectivity, and Memory Specifications
Table 15 on page 218 provides the alarms, connectivity, and memory specifications.
Table 14 Mechanical impedance analysis and resonance mode specifications
Category Parameter Va lu e
Mechanical impedance
analysis
Display modes (RUN
key)
Choice of single impedance plane (also
named XY flying dot), strip chart
(named SCAN, representing amplitude
and phase against time), split screen
(XY + SCAN)
Calibration wizard Calibration menu to determine best
frequency for application, based on
simple “BAD PART” and “GOOD
PART” measurements
Frequency range 2 kHz to 50 kHz
Gain 0 dB to 100 dB, adjustable in 0.1 dB
increments
Low-pass filter 6 Hz to 500 Hz
Dot recordings Up to 25 user-defined dot recordings
Resonance Display modes (RUN
key)
Choice of single impedance plane (also
named XY flying dot), strip chart
(named SCAN, representing amplitude
and phase against time), split screen
(XY + SCAN)
Calibration wizard Calibration menu to determine best
frequency based on the probe response
Frequency range 1 kHz to 500 kHz
Gain 0 dB to 60 dB, adjustable in 0.1 dB
increments
Low-pass filter 10 Hz to 500 Hz
Dot recordings Up to 25 user-defined dot recordings
