Olympus BondMaster 600 - Mechanical Impedance Analysis and Resonance Mode Specifications

DMTA-10045-01EN, Rev. E, August 2016
Appendix A 216
A.5 Mechanical Impedance Analysis and Resonance Mode
Specifications
Table 14 on page 217 provides the mechanical impedance analysis (MIA) and
resonance mode specifications.
Pitch-catch swept Display modes (RUN
key)
Choice of single impedance plane (also
named XY flying dot), SPECTRUM
(amplitude and phase against
frequency) and split screen (XY +
SPECTRUM)
Frequency range 5kHz to 100kHz
Gain 0 dB to 60 dB, adjustable in 0.1 dB
increments
Sweep rate LOW, MEDIUM, and HIGH user-
adjustable rate controlling the repeat
rate
Frequency tracking Up to 2 user-adjustable markers to
monitor 2 specific frequencies from the
swept figure
Table 13 Pitch‑catch tone burst and swept mode specifications (continued)
Category Parameter Va lu e
