DMTA-10045-01EN, Rev. E, August 2016
Overview of the BondMaster 600
29
Figure 2‑5 Location of the BondMaster 600 power button and indicator light
2.3.1 Charger/Adaptor
The BondMaster 600 charger/adaptor is provided with every instrument. This
charger/adaptor is the primary method for powering the BondMaster 600 with or
without a battery installed. It is also used to charge the lithium-ion rechargeable
battery when installed in the BondMaster 600. A charger/adaptor indicator light on
the front panel of the instrument displays the current status of the charger/adaptor
(see Figure 2-5 on page 29 and Figure 2-6 on page 29).
Figure 2‑6 The charger/adaptor indicator light on the front panel
Use only the power cord supplied with your BondMaster 600, unless specifically
instructed in the manual. Using an unauthorized power cord may result in damage to
the instrument or serious human injury.
Charger/adaptor
indicator light
Power button
