DMTA-10045-01EN, Rev. E, August 2016
Software User Interface 53
The BondMaster 600 applications are designed for quick setup of the instrument.
However, always follow published maintenance procedures when inspecting.
3.1.1 Navigating the Application Menu
Menu navigation is designed to be intuitive, and the settings for each application
enable immediate inspection; little or no additional instrument setup is needed.
To navigate the application menu
1. Rotate the knob to highlight one of the applications.
2. Press the Enter key ( ) to select the application.
OR
Press the Return key ( ) to go back to the BondMaster 600 main screen.
To navigate the application menu for PowerLink
 If a PowerLink probe is connected and the PowerLink recognition screen is
displayed (see Figure 3-3 on page 52), load the program stored in the PowerLink
probe, and automatically set up the BondMaster 600
, by pressing the A key.
OR
Bypass the stored program in the probe and gain access to the BondMaster 600
main inspection screen by pressing the Return key ( ).
3.1.2 Main Inspection Screen
After the initial steps are completed through the quick-setup menu or PowerLink
menu, the main inspection screen is displayed (see Figure 3-4 on page 54).
NOTE
