The VGA OUT connector allows you to connect the BondMaster 600 to a standard
analog computer monitor. The I/O connector is used to connect an external horn or, if
necessary, to connect an external control for integrating the BondMaster 600 into a
system. For PC communication details, see “MicroSD and USB Port” on page 47.
Do not expose the BondMaster 600 to harsh and wet environments while the I/O or
the VGA OUT connectors are not protected by their rubber covers. To prevent
connector corrosion and damage to the BondMaster 600, keep the rubber protective
covers on the connectors when no cables are connected.
2.5.2.3 MicroSD and USB Port
On the right-hand side of the BondMaster 600, a door covers the microSD slot and the
USB port (see Figure 2-22 on page 48). The I/O door closes against an integral
membrane seal to keep liquids away from the unsealed connectors behind it.
The BondMaster 600 utilizes 2 GB microSD memory cards for both onboard and
removable memory. The onboard 2 GB microSD card is mounted on the PC board
inside the BondMaster 600, and is responsible for all onboard data storage. In the
event that the BondMaster 600 is damaged beyond repair, this microSD card can be
removed at an authorized service center, allowing you to recover critical data from the
damaged BondMaster 600.
You can connect the BondMaster 600 to a PC via the instrument’s USB port. The
BondMaster PC interface program (Olympus P/N: B600-CD [U8141002]) is provided
with the BondMaster 600 for PC communication and file transfers. For more details,
see “BondMaster PC Software” on page 173. The BondMaster 600 can also
communicate directly with other SPC programs.
