DMTA-10045-01EN, Rev. E, August 2016
Software User Interface 59
Figure 3‑7 Example of LIVE AMPL, LIVE VERT, LIVE HORZ, and LIVE ANGL
Figure 3‑8 Example of VOLTS P‑P
3.4.1 Enabling Real-Time Readings on the Main Inspection Screen
The real-time readings are enabled through the ADV SETUP menu key ( ).
To enable the real-time readings bar on the main inspection screen
1. Press the ADV SETUP menu key ( ).
2. Press the B key.
