DMTA-10045-01EN, Rev. E, August 2016
Chapter 2
34
2.3.3 Lithium-Ion Battery
The BondMaster 600 is normally used as a portable instrument powered by the
lithium-ion battery and recharged via the charger/adapter (both are supplied with the
BondMaster 600). When properly maintained, and when the BondMaster 600 is
operated under typical inspection conditions, the lithium-ion battery should provide
between 8 and 10 hours of continuous operation.
The lithium-ion battery is not fully charged when the BondMaster 600 is shipped. You
must charge the battery for two to three hours before using battery power to operate
the BondMaster 600 (see “Charger/Adaptor” on page 29).
To install or replace the lithium-ion battery
1. Unfold the BondMaster 600 stand (see Figure 2-10 on page 35).
2. At the back of the BondMaster 600, loosen the two thumb screws securing the
battery compartment cover.
3. Remove the battery compartment cover.
4. Remove the battery and/or install the battery in the battery compartment.
5. Ensure that the gasket of the battery compartment cover is clean and in good
condition.
6. Install the battery compartment cover at the back of the BondMaster 600, and then
tighten the two thumb screws to complete the installation.
