DMTA-10045-01EN, Rev. E, August 2016
Appendix A 218
A.7 Interface Specifications
Table 16 on page 218 provides the interface specifications.
Table 15 Alarms, connectivity, and memory specifications
Category Parameter Va lu e
Alarms Quantity 3 simultaneous alarms
Available alarm types Available alarm types depend on the
BondMaster 600 model and selected
operating mode. Choice of RF alarm
(time series), BOX (rectangle), POLAR
(circle), SECTOR (pie), SCAN (time-
based), and SPEC (spectrum) featuring
selection of AMPLITUDE or PHASE.
Connectivity and
memory
PC software
BondMaster PC software, included in
base BondMaster 600 kit.
BondMaster PC enables viewing saved
files and printing reports.
On-board preview Yes, selectable with knob
Data storage 500 files
Reference signal Instant or recalled from memory
Table 16 Interface specifications
Category Parameter Va lu e
Interface presentation Languages English, Spanish, French, German,
Italian, Japanese, Chinese, Russian,
Portuguese, Polish, Dutch, Czech,
Hungarian, Swedish, and Norwegian
Colors 8 schemes to accommodate all lighting
conditions and user preferences
