DMTA-10045-01EN, Rev. E, August 2016
Control Functions 93
For parameter adjustment details, see “PC RF Mode — DISP/DOTS Menu” on
page 84. Parameter descriptions are based on the presumption that the
BondMaster 600 is set to RESON mode and the DISP/DOTS menu key ( ) has
been pressed.
5.3.9 PC RF Mode — ALARM Menu in RF RUN
The following parameters can be adjusted in the PC (RF) mode ALARM menu on RF
RUN:
• RF ALARM
•TOP
• BOTTOM
• DWELL
•HORN
The following information is applicable when the BondMaster 600 is set to PC (RF)
mode and the ALARM menu key ( ) has been pressed.
RF ALARM
The RF ALARM setting controls the RF alarm type and can be set to OFF, POS
(positive), or NEG (negative).
To change the RF ALARM setting, press the A key, and then rotate the knob to the
desired alarm type.
TOP
The TOP setting controls the alarm’s upper threshold. The displayed percentage
is a percentage of the total screen height. An example of this control is shown in
Figure 5-11 on page 94.
To change the TOP alarm threshold setting, press the B key, and then rotate the
knob to the desired alarm threshold value.
NOTE
NOTE
