DMTA-10045-01EN, Rev. E, August 2016
Control Functions
105
5.3.14 RESON Mode — Alarm Menu
The following parameters can be adjusted in the RESON (resonance) mode ALARM
menu:
• DEFINE menu:
— XY ALM 1 (XY alarm 1)
— XY ALM 2 (XY alarm 2)
— SCAN ALM (scan alarm)
— DWELL
—HORN
• XY ALM 1 (XY alarm 1) menu:
—SHAPE
• XY ALM 2 (XY alarm 2) menu:
—SHAPE
For XY ALM and SHAPE parameter adjustment details, see “PC Swept Mode —
ALARM Menu” on page 96. For SCAN ALM details, see “MIA Mode — Alarm
Menu” on page 103. For DWELL and HORN details, see “PC RF Mode — ALARM
Menu in RF RUN” on page 93. Parameter descriptions are based on the presumption
that the BondMaster 600 is set to RESON (resonance) mode and the ALARM menu
key ( ) has been pressed.
The RESON mode’s DWELL and HORN examples are shown in Figure 5-21 on
page 106 and Figure 5-22 on page 106.
