Control Functions 103
• TOP: controls the top of the BOX alarm threshold. To change the setting, press the
B key, and then rotate the knob until the threshold is in the desired position.
• BOTTOM: controls the bottom of the BOX alarm threshold. To change the setting,
press the C key, and then rotate the knob until the threshold is in the desired
position.
• LEFT: controls the left side of the BOX alarm threshold. To change the setting,
press the D key, and then rotate the knob until the threshold is in the desired
position.
• RIGHT: controls the right side of the BOX alarm threshold. To change the setting,
press the E key, and then rotate the knob until the threshold is in the desired
position.
5.3.13 MIA Mode — Alarm Menu
The following parameters can be adjusted in the MIA mode ALARM menu:
• DEFINE menu:
— SCAN ALM (scan alarm)
— XY ALM 1 (XY alarm 1)
— XY ALM 2 (XY alarm 2)
— DWELL
—HORN
• XY ALM 1 (XY alarm 1) menu:
—SHAPE
• XY ALM 2 (XY alarm 2) menu:
—SHAPE
For XY ALM and SHAPE parameter adjustment details, see “PC Swept Mode —
ALARM Menu” on page 96. For DWELL and HORN details, see “PC RF Mode —
ALARM Menu in RF RUN” on page 93. Parameter descriptions are based on the
presumption that the BondMaster 600 is set to MIA mode and the ALARM menu key
( ) has been pressed.
NOTE
