Olympus BondMaster 600 - Special Functions in the ALL SETTINGS Menu; Using the ALL SETTINGS Menu

DMTA-10045-01EN, Rev. E, August 2016
Software User Interface 57
3.3.1 Using the ALL SETTINGS Menu
The ALL SETTINGS menu is accessed through the ADV SETUP menu key ( ).
To use the ALL SETTINGS menu
1. Press the ADV SETUP menu key ( ).
2. Press the B key.
3. Press the FULL NEXT key ( ) to select the parameter to be adjusted.
4. Rotate the knob to select the desired value.
5. Press the FULL NEXT key ( ) to select additional parameters to be adjusted.
OR
Press to exit the menu and return to the previous screen.
Because of the large number of parameters that are available on the BondMaster 600,
the ALL SETTINGS menu contains multiple screens, or pages. The help text at the
bottom of the menu provides any additional navigation options that may be needed.
3.3.2 Special Functions in the ALL SETTINGS Menu
Two special instrument functions are found only in the ALL SETTINGS menu:
EXT HORN (external horn) and AOUT PWR (analog out power). These functions
enable the output connectors on the back of the BondMaster 600 (see Figure 2-21 on
page 46). To enable these functions, follow the instructions in “Using the ALL
SETTINGS Menu” on page 57.
NOTE
