DMTA-10045-01EN, Rev. E, August 2016
Chapter 5 98
Figure 5‑14 The PC Swept mode’s alarm DWELL setting control
Figure 5‑15 The PC Swept mode’s alarm HORN setting control
SHAPE
The SHAPE control is only available when the XY ALM 1 (XY alarm1) or XY ALM 2
(XY alarm 2) have been enabled. Therefore the following information is applicable
only if these alarms have been enabled.
NOTE
